Description
Features:
PixelPlus Korea image sensor
6 Glass lens
170 degree diagonal view angle
0.05 Lm minimum illumination
Variable LED lights night assist
IP68 waterproof rating
1.0Vp-p/75ohm video output
Built in parking line function, can also be disabled
Built in mirror reverse output option for front view applications
Selectable 720p AHD output
– Orange wire: AHD video signal selection; standard set from factory is CVBS video signal
– White wire: Mirror reverse output option for front view application
– Green wire: to vehicle reverse light signal to activate variable LED lights and camera guideline
